SPARTUS®
EasyMIG 375
SYNERGIC AND b IGBT MIG WITH LCD DISPLAY
Technical parameters
Input | 3× 400V ± 10% 50 / 60 Hz |
Welding current MIG [A] | 50 350 |
Duty cycle [%] | 60 |
MIG PARAMETERS | |
Output working voltage MIG [V] | 9.9 35 |
Wire feeding speed [m/min] | 0.8 16 |
Wire feeder | built-in, 4-roll gear |
Welding wire spool[kg]/[mm] | ≤ 15 / ∅200 / ∅300 |
Wire diameter ∅ [mm] | Steel 0.8 / 1.0 / 1.2 Aluminum 1.0 / 1.2 |
2T/4T Control | ![]() |
TIG PARAMETERS | |
TIG Lift | ![]() |
Welding current TIG [A] | 10 350 |
MMA PARAMETERS | |
MMA welding mode | ![]() |
Welding current MMA [A] | 10 300 |
Hot Start | ![]() |
Arc Force | ![]() |
OTHER | |
Wire test | ![]() |
Change polarity | ![]() |
Current consumption [A] | 17 |
Weight [kg] | 39 |
Dimensions [mm] | 920 × 470 × 740 |
Description:
SPARTUS® EasyMIG 375 these high-end semi-automatic welding machine (compact type),
made of inverter technology using IGBTs. It allows gas metal inert and active arc welding MIG/MAG), metal
arc
welding (MMA) and TIG Lift with arc ignition. Thanks to the ability to change polarity, it allows welding with
self-shielding wire without gas.
Max welding current is 350A for MIG/TIG, for MMA – 300A and is powered from three phase 400V source
power.
The device is equipped with synergic programs for MIG / MAG welding with steel wires in the 0,8 - 1,2mm diameter
range. Additionally, it is possible to manually correct selected parameters.
The use of modern technological solutions has allowed the device to be equipped with a number of functions that
support welding processes:
2T / 4T – selection of one of two operating modes (MIG/MAG).
Inductance – regulation of welding inductance – it allows to control the width and
depth of fusion and reduce the amount of welding splashes
Burn Back – precise adjustment of welding wire burning speed allows limit a risk of sticking
the welding wire to the contact tip.
Slow Feed – so called gentle start-up of the wire feeder, recommended especially during
welding with high amperage and high speed of wire feed.
Hot Start – for easier electrode ignition (MMA) Arc Force – for easier welding in
forced positions (MMA)
VRD – lower no-load voltage (MMA).
A high-class 4-roll wire feeder, ensures stable wire feeding of steel, aluminum and stainless steel wire. Stable
output parameters guarantee the appropriate quality of the weld.
